Monel 400

Monel 400

OriSun manufactures and stocks high strength Monel 400 bar materials available with diameter from 10 to 50 mm, up to length of 9 meters.

Monel nickel-copper alloy 400 is a solid-solution alloy that can be hardened only by cold working. It has high strength and toughness over a wide temperature range and excellent resistance to many corrosive environments. The alloy has been used in a variety of applications. It has excellent resistance to rapidly flowing brackish water or seawater. It is particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated. The alloy is slightly magnetic at room temperature. Monel 400 is widely used in the chemical, oil and marine industries.

Chemical Compositions

	Ni	C	Mn	S	Si	Cu	Fe
Max		0.3	2.00	0.024	0.5	34.0	2.50
Min	63.0					28.0

Monel 400 shows high strength and excellent corrosion resistance in a range of acidic and alkaline environments and especially suitable for reducing conditions. It also has good ductility and thermal conductivity. Monel 400 typically finds application in: marine engineering, chemical and hydro-carbon processings, heat exchangers, valves and pumps.

It is covered by the following standards: BS 3075, 3076 NA 13, DTD 204B and ASTM B164.

Large use of Monel 400 is made in the alkylation units, namely in the reacting section in contact with concentrated hydrofluoric acid.
